High design. Myriad options.

Our highest-performance railing option offers more colours in more component profiles than any railing out there. Won’t rot, warp, peel or splinter (which trumps sanding row after row of timber balusters any day) and it never needs painting or staining, ever. Talk about luxurious.

Transcend beveled deck rail in Tree House brown with black aluminum balusters
High Performance
  • Stands firm with a strong, sturdy look and feel
  • Built with the same incredible durability as Transcend decking–won’t rot, warp, peel or splinter
Trex railing product lines
Perennial Beauty
  • Modular components let you mix and match your customised look with any Trex® railing line
  • Pairs seamlessly with Transcend decking… and just as beautifully with any other Trex decking line
Trex Through & Through
  • Contains a minimum of 40% recycled material
  • Backed by the Trex 25-Year Limited Residential Warranty



Transcend® Components

Transcend is either a 5-step or 3-step process. Choose Trex post sleeves, caps and skirts (steps 1 & 2). Then choose each component separately for a custom design (steps 3–5).

A profile of Trex railing post sleeve in Tree House
1. 4” Post Sleeve
4 x 4 x 39”/108”

Actual external dimensions:
  • 4.45” x 4.45” x 40” (113mm x 113mm x 1016 mm)
  • 4.45” x 4.45” x 108” (113mm x 113mm x 2743 mm)

Fits over 4 x 4 Pressure Treated Post

A profile of Trex railing post sleeve in Tree House
1. 6” Post Sleeve
6 x 6 x 39”/108”

Actual external dimensions:
  • 5.5” x 5.5” x 39” (140 mm x 140 mm x 991 mm)
  • 5.5” x 5.5” x 108” (140 mm x 140 mm x 2743 mm)

Hollow sleeve that fits over a solid, pressure-treated post or post mount

Fits over 4 x 4 Pressure Treated Post

Available in Classic White only.

A profile of Trex railing flat post cap in Classic White as shown in the Cabin Collection
2a. Flat Post Sleeve Cap
Actual internal dimensions:
  • 4 x 4: 4.55” x 4.55” (114 mm x 114 mm)
  • 6 x 6: 5.6” x 5.6” (142 mm x 142 mm)

12 per box. Cap topping each post is the decorative finish that also withstands the weather.

6” Available in Classic White only.

Trex DeckLighting pyramid post cap light in Classic White
2a. Pyramid Post Sleeve Cap
Actual internal dimensions:
  • 4 x 4: 4.55” x 4.55” (114 mm x 114 mm)
  • 6 x 6: 5.6” x 5.6” (142 mm x 142 mm)

12 per box. Cap topping each post is the decorative finish that also withstands the weather.

6” Available in Classic White only.

A profile of Trex railing post sleeve skirt in Classic White as shown in the Cabin Collection
2b. Post Sleeve Skirt
Actual internal dimensions:
  • 4 x 4: 4.55” x 4.55” (114 mm x 114 mm)
  • 6 x 6: 5.6” x 5.6” (142 mm x 142 mm)

12 per box. Finishing piece at the base of the post that covers any cuts where the decking and railing meet. Usually coordinates with the cap.

6” Available in Classic White only.

3a. Crown Top Rail

Actual length:
  • 6’ Rail:67.5” (1.71 m)
  • 8’ Rail:91.5” (2.32 m)

Horizontal rail attached to the top of the balusters and the posts

3a/3b. Bevelled Top/Bottom Rail

Actual length:
  • 6’ Rail:67.5” (1.71 m)

Horizontal rail attached to both the top and bottom of the balusters and the posts

3a/3b. Transcend Universal Top/Bottom Rail
  • 6’ Rail:67.5” (1.71 m)
  • 8’ Rail:91.5” (2.32 m)

Horizontal rail attached to both the top and bottom of the balusters and the posts; the top rail portion serves as base for the installation of a deck board that acts as a cocktail rail

4. Square Baluster

Actual dimensions:
  • 36” Rail Height: 1.418” x 1.418” x 30.375” (36 mm x 36 mm x 772 mm)
  • 42” Rail Height: 1.418” x 1.418” x 36.375” (36 mm x 36 mm x 924 mm)

16 per pack
Vertical rungs–sometimes called spindles–that fill the space between posts

4. Round Aluminium Baluster

Actual dimensions:
  • 36” Rail Height: .75” x 30.375” (19 mm x 772 mm)
  • 42” Rail Height: .75” x 36.375” (19 mm x 924 mm)

10 per pack
Vertical rungs–sometimes called spindles–that fill the space between posts

3. Rail & Baluster Kit

Includes: Crown Top Rail, Universal Bottom Rail, Square Balusters, Adjustable Foot Block, Hardware Pack

For a simple, 3-step option choose Transcend as a rail & baluster kit.

  • 6’ x 36” Rail & Baluster Kit – Horizontal or Stair
  • 8’ x 36” Rail & Baluster Kit – Horizontal or Stair

Actual lengths: 6’ Rail: 67.5” (1.71 m); 8’ Rail: 91.5” (2.32 m)

Available in Classic White only.

5. Glass Panel Accessory Kit

6’ Rail: 67.5” (1.71 m)

Glass panel mounting hardware; glass panel not included

5. Accessory Infill Kit

Includes: 2 Baluster Spacers, Adjustable Foot Block, Mounting Hardware

Actual lengths: 6’ Rail: 67.5” (1.71 m); 8’ Rail: 91.5” (2.32 m)

Available in 6’ and 8’ lengths for square, colonial and round balusters; horizontal and stair applications.

A profile of Trex railing post sleeve in Tree House
Mounting Hardware for Cut Rails—Horizontal
Contains:
  • Qty (2) Crown Top Rail Gaskets—Horizontal
  • Qty (4) Universal Top/Bottom Rail Gaskets—Horizontal
  • Qty (2) Bevelled Top Rail Gaskets—Horizontal
  • Qty (2) Bevelled Bottom Rail Gaskets—Horizontal
  • Qty (4) RSB Rail Brackets
  • Qty (8) Rail to Bracket Fasteners—Horizontal
  • Qty (8) Rail to Post Fasteners
  • Qty (4) Screw Tip Covers
A profile of Trex railing post sleeve in Tree House
Mounting Hardware for Cut Rails—Stair
Contains:
  • Qty (1) Crown Top 1 Rail Gaskets—Stair
  • Qty (1) Crown Top 2 Rail Gaskets—Stair
  • Qty (2) Universal Top/Bottom 1 Rail Gaskets—Stair
  • Qty (2) Universal Top/Bottom 2 Rail Gaskets—Stair
  • Qty (1) Bevelled Top Rail 1 Gaskets—Stair
  • Qty (1) Bevelled Top Rail 2 Gaskets—Stair
  • Qty (1) Bevelled Bottom Rail 1 Gaskets—Stair
  • Qty (1) Bevelled Bottom Rail 2 Gaskets—Stair
  • Qty (8) RSB Rail Brackets
  • Qty (8) Rail to Bracket Fasteners— Stair
  • Qty (8) Rail to Post Fasteners
  • Qty (4) Screw Tip Covers
A profile of Trex railing flat post cap in Classic White as shown in the Cabin Collection
RSB Bracket Pack—Horizontal
Contains:
  • Qty (4) RSB Rail Brackets
  • Qty (8) Rail to Bracket Fasteners—Horizontal
  • Qty (8) Rail to Post Fasteners
A profile of Trex railing post sleeve in Tree House
RSB Bracket Pack—Stair
Contains:
  • Qty (8) RSB Rail Brackets
  • Qty (8) Rail to Bracket Fasteners—Stair
  • Qty (8) Rail to Post Fasteners
A profile of Trex railing post sleeve in Tree House
0 Degree Rail Gasket Pack—Horizontal
Contains:
  • Qty (2) Crown Top Rail Gaskets—Horizontal
  • Qty (4) Universal Top/Bottom Rail Gaskets—Horizontal
  • Qty (2) Bevelled Top Rail Gaskets—Horizontal
  • Qty (2) Bevelled Bottom Rail Gaskets—Horizontal
A profile of Trex railing flat post cap in Classic White as shown in the Cabin Collection
0 Degree Rail Gasket Pack—Stair
Contains:
  • Qty (1) Crown Top 1 Rail Gaskets—Stair
  • Qty (1) Crown Top 2 Rail Gaskets—Stair
  • Qty (2) Universal Top/Bottom 1 Rail Gaskets—Stair
  • Qty (2) Universal Top/Bottom 2 Rail Gaskets—Stair
  • Qty (1) Bevelled Top Rail 1 Gaskets—Stair
  • Qty (1) Bevelled Top Rail 2 Gaskets—Stair
  • Qty (1) Bevelled Bottom Rail 1 Gaskets—Stair
  • Qty (1) Bevelled Bottom Rail 2 Gaskets—Stair
A profile of Trex railing post sleeve in Tree House
22.5 Degree Rail Gasket Pack—Horizontal
Contains:
  • Qty (2) Crown Top Rail Gaskets—22.5
  • Qty (4) Universal Top/Bottom 1 Rail Gaskets—22.5
  • Qty (2) Bevelled Top Rail 1 Gaskets—22.5
  • Qty (2) Bevelled Top Rail 2 Gaskets—22.5
  • Qty (2) Bevelled Bottom Rail 1 Gaskets—22.5
  • Qty (2) Bevelled Bottom Rail 2 Gaskets—22.5
A profile of Trex railing post sleeve in Tree House
45 Degree ”Birds-Mouth” Rail Gasket Pack—Horizontal
Contains:
  • Qty (4) 45degree Adapters for RSB Rail Brackets
  • Qty (2) Crown Top Rail Birds-mouth Gaskets—45
  • Qty (4) Universal Top/Bottom Rail Birds-mouth Gaskets—45
A profile of Trex railing flat post cap in Classic White as shown in the Cabin Collection
45 Degree Rail Gasket Pack—Horizontal
Crown Rail Contains:
  • Qty (2) Crown Top Rail Gaskets- 45
  • Qty (4) Universal Top/Bottom Rail Gaskets- 45
Bevelled Rail Contains:
  • Qty (2) Bevelled Top Rail 1 Gaskets- 45
  • Qty (2) Bevelled Top Rail 2 Gaskets- 45
  • Qty (2) Bevelled Bottom Rail 1 Gaskets- 45
  • Qty (2) Bevelled Bottom Rail 2 Gaskets- 45
A profile of Trex railing post sleeve in Tree House
Adjustable Footblock
Contains:
  • Qty (1) Adjustable Footblock
  • Qty (1) Base and Base Fastener
  • Qty (1) Locking Fastener and Screw Cap
